XT200 یک آببند میلهای نوآورانه است که برای کاربردهای چالشبرانگیز در دمای بالا که به مقاومت اکستروژن و نشتی کم نیاز دارند، توسعه یافته است.
| Product | d (f8) | D (H10) | L (+0.2/-0) | H | Kastaş Code |
|---|
| XT200-020 | 20 | 28 | 6.3 | 5.7 | 10054125 |
| XT200-020/1 | 20 | 30 | 7 | 6.3 | 10054131 |
| XT200-020/2 | 20 | 30 | 9 | 8 | 10054133 |
| XT200-022 | 22 | 30 | 6.3 | 5.7 | 10043977 |
| XT200-025 | 25 | 33 | 6.3 | 5.7 | 10043973 |
| XT200-025/1 | 25 | 35 | 9 | 8 | 10054134 |
| XT200-025/2 | 25 | 33 | 5.6 | 5 | 10054135 |
| XT200-025/3 | 25 | 35 | 8 | 7.3 | 10054233 |
| XT200-028 | 28 | 36 | 6.3 | 5.7 | 10054136 |
| XT200-028/1 | 28 | 38 | 9 | 8 | 10054137 |
| XT200-030 | 30 | 38 | 6.3 | 5.7 | 10054138 |
| XT200-030/1 | 30 | 40 | 9 | 8 | 10037843 |
| XT200-030/2 | 30 | 45 | 11 | 10 | 10054139 |
| XT200-030/3 | 30 | 40 | 6.7 | 6 | 10054140 |
| XT200-032 | 32 | 40 | 6.3 | 5.7 | 10054141 |
| XT200-032/1 | 32 | 42 | 9 | 8 | 10054142 |
| XT200-035 | 35 | 43 | 6.3 | 5.7 | 10054143 |
| XT200-035/1 | 35 | 45 | 9 | 8 | 10037844 |
| XT200-035/2 | 35 | 50 | 11 | 10 | 10054144 |
| XT200-035/3 | 35 | 48 | 9 | 8.3 | 10054234 |
| XT200-038 | 38 | 46 | 6.3 | 5.7 | 10054145 |
| XT200-040 | 40 | 48 | 6.3 | 5.7 | 10037845 |
| XT200-040/1 | 40 | 50 | 9 | 8 | 10037846 |
| XT200-040/2 | 40 | 55 | 11 | 10 | 10054146 |
| XT200-045 | 45 | 55 | 6.3 | 5.7 | 10054147 |
| XT200-045/1 | 45 | 58 | 9 | 8 | 10054148 |
| XT200-045/2 | 45 | 60 | 11 | 10 | 10054149 |
| XT200-050 | 50 | 60 | 6.3 | 5.7 | 10037847 |
| XT200-050/1 | 50 | 63 | 9 | 8 | 10037848 |
| XT200-050/2 | 50 | 65 | 11 | 10 | 10054150 |
| XT200-050/3 | 50 | 70 | 14 | 12.5 | 10054151 |
| XT200-050/4 | 50 | 60 | 9 | 8.3 | 10054235 |
| XT200-055 | 55 | 65 | 6.3 | 5.7 | 10054152 |
| XT200-055/1 | 55 | 70 | 11 | 10 | 10054153 |
| XT200-056 | 56 | 68 | 9 | 8 | 10054154 |
| XT200-060 | 60 | 70 | 6.3 | 5.7 | 10037849 |
| XT200-060/1 | 60 | 75 | 11 | 10 | 10037850 |
| XT200-060/2 | 60 | 80 | 14 | 12.5 | 10054155 |
| XT200-063 | 63 | 75 | 9 | 8 | 10054156 |
| XT200-065 | 65 | 80 | 11 | 10 | 10054157 |
| XT200-070 | 70 | 80 | 6.3 | 5.7 | 10054158 |
| XT200-070/1 | 70 | 85 | 11 | 10 | 10037851 |
| XT200-070/2 | 70 | 90 | 14 | 12.5 | 10054159 |
| XT200-075 | 75 | 90 | 11 | 10 | 10037852 |
| XT200-080 | 80 | 90 | 6.3 | 5.7 | 10054160 |
| XT200-080/1 | 80 | 95 | 11 | 10 | 10037853 |
| XT200-080/2 | 80 | 100 | 14 | 12.5 | 10054161 |
| XT200-085 | 85 | 100 | 11 | 10 | 10054162 |
| XT200-090 | 90 | 100 | 6.3 | 5.7 | 10054163 |
| XT200-090/1 | 90 | 105 | 11 | 10 | 10054164 |
| XT200-090/2 | 90 | 110 | 14 | 12.5 | 10054165 |
| XT200-095 | 95 | 110 | 11 | 10 | 10054166 |
| XT200-100 | 100 | 110 | 6.3 | 5.7 | 10054167 |
| XT200-100/1 | 100 | 115 | 11 | 10 | 10037854 |
| XT200-100/2 | 100 | 120 | 14 | 12.5 | 10054168 |
| XT200-100/3 | 100 | 125 | 16 | 14.5 | 10054169 |
| XT200-110 | 110 | 125 | 11 | 10 | 10054170 |
| XT200-115 | 115 | 135 | 14 | 12.5 | 10054171 |
| XT200-120 | 120 | 135 | 11 | 10 | 10054172 |
| XT200-120/1 | 120 | 140 | 14 | 12.5 | 10054173 |
| XT200-125 | 125 | 140 | 11 | 10 | 10037855 |
| XT200-125/1 | 125 | 150 | 16 | 14.5 | 10054174 |
| XT200-130 | 130 | 150 | 14 | 12.5 | 10054175 |
| XT200-135 | 135 | 155 | 14 | 12.5 | 10054176 |
| XT200-140 | 140 | 160 | 14 | 12.5 | 10054177 |
| XT200-145 | 145 | 165 | 14 | 12.5 | 10054178 |
| XT200-150 | 150 | 170 | 14 | 12.5 | 10037856 |
| XT200-150/1 | 150 | 175 | 16 | 14.5 | 10054179 |
| XT200-160 | 160 | 180 | 14 | 12.5 | 10054180 |
| XT200-160/1 | 160 | 185 | 16 | 14.5 | 10054181 |
| XT200-170 | 170 | 190 | 14 | 12.5 | 10054182 |
| XT200-170/1 | 170 | 195 | 16 | 14.5 | 10054183 |
| XT200-180 | 180 | 200 | 14 | 12.5 | 10054184 |
| XT200-180/1 | 180 | 205 | 16 | 14.5 | 10054185 |
| XT200-190 | 190 | 210 | 14 | 12.5 | 10054186 |
| XT200-200 | 200 | 220 | 14 | 12.5 | 10037857 |
| XT200-200/1 | 200 | 225 | 16 | 14.5 | 10054187 |
| XT200-200/2 | 200 | 230 | 19 | 17 | 10054188 |
| XT200-210 | 210 | 230 | 14 | 12.5 | 10054189 |
| XT200-220 | 220 | 240 | 14 | 12.5 | 10054190 |
| XT200-225 | 225 | 250 | 19 | 17 | 10054191 |
| XT200-230 | 230 | 250 | 14 | 12.5 | 10054192 |
| XT200-240 | 240 | 260 | 14 | 12.5 | 10054193 |
| XT200-250 | 250 | 270 | 14 | 12.5 | 10054194 |
| XT200-250/1 | 250 | 275 | 16 | 14.5 | 10054195 |
| XT200-250/2 | 250 | 280 | 19 | 17 | 10054196 |
| XT200-260 | 260 | 285 | 16 | 14.5 | 10054197 |
| XT200-270 | 270 | 295 | 16 | 14.5 | 10054198 |
| XT200-280 | 280 | 305 | 16 | 14.5 | 10054199 |
| XT200-290 | 290 | 315 | 16 | 14.5 | 10054200 |
| XT200-300 | 300 | 325 | 16 | 14.5 | 10037858 |
| XT200-300/1 | 300 | 330 | 19 | 17 | 10054201 |
| XT200-310 | 310 | 340 | 19 | 17 | 10054202 |
| XT200-320 | 320 | 350 | 19 | 17 | 10054203 |
| XT200-330 | 330 | 360 | 19 | 17 | 10054204 |
| XT200-340 | 340 | 370 | 19 | 17 | 10054205 |
| XT200-350 | 350 | 380 | 19 | 17 | 10054206 |
| XT200-360 | 360 | 390 | 19 | 17 | 10054207 |
| XT200-370 | 370 | 400 | 19 | 17 | 10054208 |
| XT200-380 | 380 | 410 | 19 | 17 | 10054209 |
| XT200-390 | 390 | 420 | 19 | 17 | 10054210 |
| XT200-400 | 400 | 430 | 19 | 17 | 10054211 |
| XT200-410 | 410 | 440 | 19 | 17 | 10054212 |
| XT200-420 | 420 | 450 | 19 | 17 | 10054213 |
| XT200-430 | 430 | 460 | 19 | 17 | 10054214 |
| XT200-440 | 440 | 470 | 19 | 17 | 10054215 |
| XT200-450 | 450 | 480 | 19 | 17 | 10054216 |
| XT200-460 | 460 | 490 | 19 | 17 | 10054217 |
| XT200-470 | 470 | 500 | 19 | 17 | 10054218 |
| XT200-480 | 480 | 510 | 19 | 17 | 10054219 |
| XT200-490 | 490 | 520 | 19 | 17 | 10054220 |
| XT200-500 | 500 | 530 | 19 | 17 | 10037859 |
| XT200-500/1 | 500 | 540 | 25 | 22.5 | 10054221 |
